What is the Simplex 2975-9452?

The Simplex 2975-9452 is a combined box and solid door for the 4100ES fire alarm platform: platinum finish, 3-bay size, shipped together as a single package. It is the packaged equivalent of the 2975-9440 platinum 3-bay box plus the 4100-2116 platinum 3-bay solid door. Simplex specifies solid doors for MINIPLEX transponders and utility function cabinets, where nobody needs to see the modules inside; control panels, NDUs, and annunciators normally take the glass door version with dress panel (2975-9446) instead.

The cabinet holds three equipment bays with a battery bay at the bottom, accepts battery sets up to 50 Ah, and is rated NEMA 1 (wall mount enclosures are also IP30). The source for every specification on this page is Simplex datasheet S4100-0037, the 4100ES cabinet reference.

Key features

• Combined part number: 3-bay box and solid door ship as one package
• Platinum finish; red equivalent is the 2975-9449
• 56 in. (1422 mm) tall, 24 in. (610 mm) wide, box depth 6-29/32 in. (175 mm)
• Three equipment bays plus dedicated battery bay at the bottom
• Battery capacity from 6.2 to 50 Ah (50 Ah requires the 4100-0650 battery shelf)
• NEMA 1 enclosure rating; IP30 as a wall mount enclosure
• Door hinges left or right; opens 90 degrees at minimum protrusion, 180 degrees with 3 in. or more of exposed cabinet
• Simplex "B" key lock; replacement key part 252-019
• Semi-flush mounting knockouts, stud alignment markers for 4 in. and 6 in. studs, and smooth surfaces for field-cut conduit entries
• UL, ULC, and CSFM listed; FM Approved; NYC MEA35-93E acceptance (per S4100-0037)

Complete specifications

Choosing the right 4100ES cabinet

Simplex publishes a combined box and door selection matrix in S4100-0037 (Table 1). Pick the door type by function, the color by site standard, and the bay count by how much equipment and battery capacity the cabinet has to hold. The 2975-9452 is the platinum 3-bay solid door option, highlighted below.

How to choose:

• Solid door (this product): MINIPLEX transponders and utility function cabinets. No module visibility, no dress panel needed.
• Glass door with dress panel: control panels, NDUs, and annunciators, where operators and inspectors need to see displays and module status.
• Separate components: the same configuration as the 2975-9452 can be ordered as the 2975-9440 platinum 3-bay box plus the 4100-2116 platinum 3-bay solid door. The combined part number ships as a single package.

Applications

• MINIPLEX transponder enclosures. The solid door is the configuration Simplex specifies for 4100ES MINIPLEX transponders; for ULC (Canadian) installations, add the 4100-9837 green LED power-on indicator kit in the door knockout.
• Utility function cabinets. Power supplies, distribution, and other equipment that no one needs to view during normal operation.
• Battery capacity upgrades. The bottom battery bay takes sealed lead-acid sets from 6.2 Ah up to 50 Ah, so a 3-bay cabinet covers systems with large standby requirements (50 Ah sets need the 4100-0650 shelf).
• Semi-flush architectural installs. Knockouts, stud markers, and the 2975-9813 trim support recessed mounting in finished walls; the platinum finish is the non-red option in the 4100ES line for those spaces.

Compatibility

• Platform: Simplex 4100ES fire alarm systems, per cabinet reference S4100-0037. Solid door specified for MINIPLEX transponders and utility cabinets.
• Batteries: two 12 VDC sealed lead-acid per set, 6.2 to 50 Ah: Simplex 2081-9272, 2081-9274, 2081-9288, 2081-9275, 2081-9287, 2081-9276, 2081-9296. The 50 Ah set requires the 4100-0650 battery shelf.
• Power distribution: one PDM per box, ordered separately: 4100-0634 (120 VAC) or 4100-0635 (220/230/240 VAC).
• Mounting accessory: 2975-9813 platinum semi-flush box trim, 1-7/16 in. (37 mm) wide.
• Lock: Simplex "B" key; replacement key 252-019.
• ULC installations: 4100-9837 green LED power-on indicator kit for MINIPLEX transponder listing.
• Siblings: 2975-9450 / 2975-9451 (platinum 1 and 2 bay, solid door), 2975-9447 / 2975-9448 / 2975-9449 (red 1, 2, 3 bay, solid door), 2975-9441 to 2975-9446 (glass door with dress panel).

What's in the box

• 4100ES platinum 3-bay box
• Platinum solid door, factory-combined with the box in a single shipping package

Keys ship with the system master controller, not with the cabinet (replacement key: 252-019). The power distribution module, batteries, battery shelf, and semi-flush trim are ordered separately.

Certifications and standards

• UL Listed
• ULC Listed (with the 4100-9837 LED kit required for MINIPLEX transponder configurations)
• CSFM Listed
• FM Approved
• NYC MEA35-93E acceptance

Listings are stated at the document level in Simplex datasheet S4100-0037. Install per NFPA 72 and the requirements of your local AHJ.

Installation notes

The cabinet wall-mounts surface or semi-flush. For semi-flush work, the box has knockout screw and nail holes, stud alignment markers for 4 in. (102 mm) and 6 in. (152 mm) studs, and the 2975-9813 platinum trim (1-7/16 in. wide) finishes the reveal. Conduit entries are field-cut on the smooth, unembossed surfaces of the box.

The door can be hinged on either side. Plan clearance for the swing: 90 degrees of opening at minimum protrusion, or 180 degrees when 3 in. (76 mm) or more of the cabinet is exposed from the wall. Depth with the door attached is 11-11/16 in. (296 mm) total reference, with the door itself at 4-3/4 in. (121 mm).

Fit one power distribution module per box (4100-0634 for 120 VAC, 4100-0635 for 220/230/240 VAC) and place batteries in the bottom bay; a 50 Ah set requires the 4100-0650 battery shelf. Simplex installation instructions 579-117 cover the cabinet; keep them with the system documentation for inspections.

Frequently asked questions

Which Simplex panels does the 2975-9452 fit?

It is a 4100ES-platform cabinet, documented in the S4100-0037 cabinet reference. Simplex specifies the solid door configuration for MINIPLEX transponders and utility function cabinets. Control panels, NDUs, and annunciators that need visible modules normally use the glass door equivalent, 2975-9446.

Does the 2975-9452 include both the box and the door?

Yes. It is a combined part number that ships as a single package. The equivalent separate components are the 2975-9440 platinum 3-bay box and the 4100-2116 platinum 3-bay solid door.

What are the cabinet dimensions?

The 3-bay box is 56 in. (1422 mm) tall and 24 in. (610 mm) wide, with a box depth of 6-29/32 in. (175 mm). With the solid door attached, the total depth reference is 11-11/16 in. (296 mm); the door itself is 4-3/4 in. (121 mm) thick.

What batteries fit in the battery bay?

Two 12 VDC sealed lead-acid batteries per set, from 6.2 to 50 Ah: Simplex 2081-9272, -9274, -9288, -9275, -9287, -9276, or -9296. The 50 Ah set requires the 4100-0650 battery shelf.

Do I need a power distribution module?

Yes. Simplex requires one PDM per 4100ES box, ordered separately: 4100-0634 for 120 VAC service or 4100-0635 for 220/230/240 VAC.

Can the cabinet be semi-flush mounted?

Yes. The box has knockout screw and nail holes for semi-flush mounting and stud alignment markers for 4 in. and 6 in. studs. The 2975-9813 platinum semi-flush trim, 1-7/16 in. (37 mm) wide, finishes the installation.

Which key does the door lock use?

The Simplex "B" key. Keys ship with the system master controller rather than with the cabinet; the replacement key part number is 252-019.

Is this cabinet available in red or in other sizes?

Yes. The solid door series runs 2975-9450 (platinum 1 bay), 2975-9451 (platinum 2 bay), 2975-9452 (platinum 3 bay, this product), and 2975-9447 / 2975-9448 / 2975-9449 for red 1, 2, and 3 bay. Glass door versions with dress panels run 2975-9441 through 2975-9446.

Is anything extra required for ULC (Canadian) installations?

For ULC listing of a MINIPLEX transponder in a solid door cabinet, Simplex requires the 4100-9837 green LED power-on indicator kit, which mounts in a knockout on the solid door.
